QY-P101C1C2
CPU: High performance quad core processor
GPU: Mali-T764 GPU
RAM: 2GB DDR3
Flash: 8GB eMMC with 16GB eMMC/32GB eMMC
Ethernet: 10/100Mbps
| параметры | |||
|---|---|---|---|
| CPU | High performance quad core processor | GPU | Mali-T764 GPU |
| RAM | 2GB DDR3 | Flash | 8GB eMMC with 16GB eMMC/32GB eMMC |
| Ethernet | 10/100Mbps | UART | UART TTLx1, with a baud rate of 9600bps~115200bps; RS232 serial port x2 (optional), baud rate support 9600bps~115200bps; RS485x1 (optional), baud rate support 9600bps~115200bps |
| Overall size | 251.50mm*170.10mm*34.10mm | USB | USB 2.0 Hostx4、 USB 2.0 OTGx1 |
| Audio | Digital audio microphone (optional) | Plate | Galvanized sheet+aluminum profile |
| Wi-Fi/BT | 2.4GHz Wi Fi, supporting 802.11 b/g/n protocol, supporting BT4.2 4G LTE network (optional) | Speaker | 8 Ω 2W horn |
| VPU | Supports 4K 10bits H265/H264 video decoding 1080P multi format video decoding (VC-1, MPEG-1/2/4, VP8) 1080P video encoding, supports H.264, VP8 formats | Camera | 2 megapixel camera (optional) |
| Power Supply | DC 5.5mm * 2.5mm (DC12V input) | Operating System | support Android5.1/Android7.1 |
| Power Consumption | 12W | Operating Temperature | -10℃ ~ +60℃ |
| Working Humidity | 5%~95%, non condensing | 4G | Supports 4G LTE all network connectivity (optional) |
| SIM Card | SIM card slot | Storage temperature | -20℃ ~ +70℃ |
| LED | Power indicator x1 (red), system operation indicator x1 (green) | Headphone interface | 3.5mm headphone socket |
| Resolution Ratio | 800*1280 | Touch Screen | capacitive |
| Brightness | 450 CD/M2 | Panel Size | 10.1 inch |
| Power interface | DC12V-2.5A | Box Weight | 1.2KG |
| Protective level | Integrated IP50 protection design | ||
