IAC-RK3568-Kit
CPU: RockChip RK3568 Quad ARM® Cortex™-A55
Frequency: 2.0 GHz
GPU: Mali-G52-2EE supports OpenGL ES 1.1/2.0/3.2, OpenCL 2.0, Vulkan 1.1 Embedded high performance 2D acceleration hardware
VPU: 4K 60fps H.265/H.264/VP9 video decoding 1080P 60fps H.265/H.264 video encoding 8-meter ISP supports HDR
NPU: 1TOPS
| параметры | |||
|---|---|---|---|
| CPU | RockChip RK3568 Quad ARM® Cortex™-A55 | Frequency | 2.0 GHz |
| GPU | Mali-G52-2EE supports OpenGL ES 1.1/2.0/3.2, OpenCL 2.0, Vulkan 1.1 Embedded high performance 2D acceleration hardware | VPU | 4K 60fps H.265/H.264/VP9 video decoding 1080P 60fps H.265/H.264 video encoding 8-meter ISP supports HDR |
| NPU | 1TOPS | RAM | 2GB LPDDR4 |
| Flash | 8GB eMMC，(16GB eMMC、32GB eMMC option) | PMIC | RockChip RK809 |
| Ethernet | 2 *10M/100M/1000M | Wi-Fi | Onboard WiFi module, support 2.4GHz/5GHz dual-band WiFi, 802.11a/b/g/n/ac protocol |
| UART | 1 *UART debugging serial port; 2 * RS232 serial port; 1 * RS485 | CAN | 3 * CAN |
| Display Interface | 2 * MIPI_DSI display interface (1 multiplexing LVDS), resolution up to 1920x1080@60Hz 1 * LVDS display interface, resolution up to 1280x800@60Hz 1 * HDMI display interface (HDMI2.0), resolution up to 4096x2160@60Hz 1 * eDP display interface, resolution up to 2560x1600@60Hz | Audio | Audio (power amplifier) output interface; Dual channel audio output (headphone socket); Single channel MIC audio input |
| USB | 2 * USB2.0 HOST ; 1 * USB Type-c | Camera | 2* MIPI-CSI (4 channels), support two cameras input at the same time, resolution support 2*1080p@80Hz |
| Input Interface | Standard I2C capacitor screen interface | Extension Interface | 8* GPIO (1.8 v)；MINI-PCIE port (USB2.0) connects to 4G modules. M.2 B-KEY ports for connecting to 5G modules and SIM cards; (one of two options) |
| Storage interface | 1 * TF card; 1 * SATA | Other | Reset circuit, watchdog circuit, real-time clock |
| Power Supply | +12V | Size | Core board: 65mm*70mm, 8 layer；Carrier board: 200mm*140mm, 4 layers |
| Power Consumption | ＜3W | Operating Temperature | 0°C ~ +70°C（-40°C ~ +85°C optional） |
| Working Humidity | 10%~ 90%, non-condensation | Operating System | Android 11, Debian10 |
| характеристики | |||
|---|---|---|---|
| J35 | DC12V Power In | D26 | Power indicator, system running indicator |
| J28 | Headphone socket (dual channel audio output) | J33 | TF |
| J6 | Type-c | J1 | Gigabit Ethernet |
| J2 | Gigabit Ethernet | J7 | USB2.0 HOST(2*USB2.0) |
| J17 | HDMI | BT1 | RTC cell |
| SW1 | RESET Button | J10 | RS485 |
| J11 | RS232 | J12 | Debug |
| J14 | CAN | J18 | 3.3V/5V jump wire |
| J19 | LVDS | J13 | RS232 |
| J34 | SPI、I2C | J16 | CAN |
| J15 | CAN | J22 | MIPI-DSI |
| J26 | MIPI-CSI | J27 | MIPI-CSI |
| J32 | WiFi-IPEX | J23 | I2C（TP） |
| J31 | Speaker output | J21 | EDP |
| J20 | 3.3V/5V jump wire | J9 | SATA |
| J8 | SATA power supply | J25 | Blacklight (12V/5V) |
| U20 | WiFi module | J29 | I2S、I2C |
| J30 | MIC input | J24 | 12V/5V jump wire |
| J3 | MINI-PCIE | J4 | M.2 B-KEY |
| J5 | USB-OTG（HOST/Device） | S1 | SIM Card slot |
| SW2 | PMIC-POWER button | SW3-7 | Function key |
| SW8 | Recovery Button | ||
