QY-RK3288S
CPU: Rockchip RK3288
Architecture: Cortex-A17 Quad-Core
Frequency: 1.8GHz
GPU: Mali-T764, support AFBC
RAM: DDR3 SDRAM, 4*512MB, total 2GB
| параметры | |||
|---|---|---|---|
| CPU | Rockchip RK3288 | Architecture | Cortex-A17 Quad-Core |
| Frequency | 1.8GHz | GPU | Mali-T764, support AFBC |
| RAM | DDR3 SDRAM, 4*512MB, total 2GB | Flash | 8GB EMMC |
| UART | 5*RS232 (4*RS232,1*Debug) | Ethernet | 1*10M/100M/1000Mbps |
| USB | 1*USB OTG, 4*USB HOST | Wi-Fi/BT | Onboard Wi-Fi&BT Module |
| I2C | Standard I2C capacitive screen connection | Display Interface | 1*Dual-channel LVDS interface, support 30Bit ； HDMI,support HDMI2.0,MAX.4K*2K@60Hz |
| Audio | MIC,Speaker | Camera | 1*MIPI-CSI |
| Storage interface | TF card | Extension Interface | SIM Card |
| Other | Reset Circuit,RTC | Power Supply | +12V, Support +9V~+16V |
| Operating System | Android 5.1 | Size | 156mm*106mm |
| Power Consumption | ≤3W | Operating Temperature | -10℃~+60℃ |
| Working Humidity | 5% ~ 95%, non-condensing | ||
| характеристики | |||
|---|---|---|---|
| J1 | Power Switch Interface | J2 | +12V Power Input |
| J6 | 4-PIN USB | J7 | 4-PIN USB |
| J8 | MINI-USB | J9 | Gigabit Ethernet |
| J11 | Speaker | J12 | MIC |
| J13 | HDMI | J15 | MINI-PCIE |
| J16 | LVDS | J17 | Backlight Power Supply |
| J21 | MIPI-CSI | J30 | Capacitive Touch Screen Interface (I2C & GPIO) |
| J31 | 12*GPIO | J35 | KEY Interface (Reserved interface) |
| J39 | Double Stack USB Interface | J40 | RS232 (COM3) |
| J41 | RS232 (COM1) | J42 | Multiplex Interface (COM0) |
| J43 | RS232 (COM4) | J44 | RS232 (Debug Port) |
| J45 | Power Input | J47 | Antenna |
| U21 | TF Card | BT1 | System Clock Power Supply (+ 3.0V) |
| SW1 | Recovery Button (For flashing use) | SW2 | System Reset Button |
| SW5 | Power Reset Button | ||
